Фурнитура и комплектующие (UMT-HW-KIT) is a RoHS / CE-certified фурнитура и аксессуары product manufactured by UREXCEED. Lead time: 25 – 40 days (tooling) · then ships with main equipment. MOQ: Consolidated into main equipment shipment — no standalone MOQ. Key applications: Bundled with refrigerator OEM line orders (chef base / display cabinet / chest freezer / commercial freezer), Bundled with cold-room panel + door-frame projects (specialty bracketry for blast-freezer entrances), Custom-fabricated per buyer drawing — no catalog SKU, no standalone hardware orders.
UMT-HW-KIT
Фурнитура и комплектующие
Петли, уплотнения, ручки, LED освещение, испарители и конденсаторы
Engineering reply within 24 hours
Quote + spec sheet + tailored sizing recommendation. WhatsApp answered 9 am–6 pm Beijing time.
Характеристики
- Scope of Service
- Complementary hardware fabrication — supplied alongside the main equipment order (moulds / PU foaming / production line). NOT sold as a standalone product line. Custom-fabricated per your drawings.
- Category 1 · Hinges
- Stamped-steel hinges for refrigerator / freezer / display-cabinet / chef-base / wine-cabinet doors. 30+ standard profiles in our catalog (AO17, L1000, LC1600, 单门陈列柜系列, 四六门系列, 反铰链, 回归铰链 etc.). All custom-sized to your drawing.
- Category 2 · Brackets & Liners
- Cabinet reinforcement brackets, hinge liner plates (箱壳铰链衬铁), triangle plates (三角片), wine-cabinet brackets, ventilation grille brackets. Custom per drawing.
- Category 3 · Rails & Ladders (轨道 / 天梯)
- Compressor base plates (压机板), roller plates (轮子板), aluminium ladders with holes (小孔 / 大孔带耳铝天梯), stainless ladders (不锈钢天梯, multi-spec). Length custom.
- Category 4 · Wire Shelves & Baskets
- Display-cabinet shelves (陈列柜网片), cake-cabinet racks, island-freezer baskets (岛柜平蓝 / 网蓝), anti-tip racks (防倒架), salad-bar grid panels (点菜柜网片). Chrome / epoxy / e-coat finish.
- Category 5 · Grid Panels (网片)
- Air-cooled shelves (风冷网片), static-cooled shelves (平冷网片), meat-cabinet racks (肉柜架), 4-door / 6-door cabinet shelves (四门 / 六门网片), wine-cabinet shelves (红酒柜网片), ventilation panels (通风片).
- Customization
- Every item is "可定制" — we fabricate to your drawing. Tooling lead time 25–40 days for new dies; thereafter parts ship on your main equipment schedule.
- Finish Options
- Zinc electroplating (8–12 µm, default) · chrome plating (visible display hardware) · epoxy powder coating (any RAL color, wire shelves) · e-coating cathodic (480 h+ salt-spray for coastal / humid markets)
- QC Documentation
- Salt-spray test report (ASTM B117) · plating thickness report · material certs · FAI for new dies. Shipped with goods.
- Order Flow
- Hardware is consolidated into your main equipment shipment — one invoice, one lead time, no separate logistics. Not sold separately.
- Reference Catalog
- Full 17-page hardware catalog: /downloads/urexceed-hardware-catalog.pdf
Применение
- Bundled with refrigerator OEM line orders (chef base / display cabinet / chest freezer / commercial freezer)
- Bundled with cold-room panel + door-frame projects (specialty bracketry for blast-freezer entrances)
- Custom-fabricated per buyer drawing — no catalog SKU, no standalone hardware orders
Сертификаты
Complementary service · not a standalone product line. Hardware is a complementary fabrication service we offer alongside our main equipment orders — not a standalone product line. Every item is custom-fabricated per your drawings, consolidated into your main equipment shipment. No catalog SKUs sold separately.
Five hardware categories — all custom-fabricated per your drawing
Our 17-page hardware catalog covers 5 categories with 70+ standard reference profiles. Each item is "可定制" (customizable): stamped, plated, finished to your drawing. Below: the 5 categories at a glance — download the catalog PDF for full reference profiles.
Hinges (铰链) — 30+ reference profiles
Stamped-steel hinges for refrigerator / freezer / display-cabinet / chef-base / wine-cabinet doors. Catalog families: AO17, L1000, LC1600, 单门陈列柜 series, 四六门 series, 反铰链 (reverse hinges), 回归铰链 (self-closing). Each profile sized to your door weight and gasket compression.
Brackets & liners (支架 / 衬铁)
Cabinet hinge liner plates (箱壳铰链衬铁), triangle plates (前三角片 / 三角片), wine-cabinet brackets (酒柜左右上), reverse-flow vent brackets (直风冷方孔 / 风铃方孔), fixed foot plates (固定脚片). Stamped cold-rolled steel.
Rails & ladders (轨道 / 天梯)
Compressor base plates (压机板), roller mounting plates (轮子板), aluminium ladders with small holes (小孔铝天梯, 1315 mm typical), large-hole aluminium ladders (大孔带耳铝天梯, 1330 mm), stainless steel ladders (不锈钢天梯, 610–1180 mm pitch options). Lengths fully custom.
Wire shelves & baskets (网架 / 网篮)
Display-cabinet wire shelves (陈列柜网片), cake-cabinet shelves (蛋糕柜架), island-freezer flat baskets (岛柜平蓝), island-freezer wire baskets (岛柜网蓝 large + small), anti-tip rack (防倒架), salad-bar grid panel (点菜柜网片). Welded chrome / epoxy / e-coat finish.
Grid panels (网片)
Air-cooled cabinet shelves (风冷网片), static-cooled cabinet shelves (平冷网片), meat-display cabinet shelves (肉柜架), 4-door / 6-door cabinet shelves (四门 / 六门网片), wine-cabinet shelves (红酒柜网片), ventilation panels (通风片). Welded wire frame, food-contact safe coating.
Why we bundle hardware with the main equipment — not sell it separately
Fit is validated, not assumed — hinge geometry checked against your door mould and gasket. Doors seal on first assembly, no rework.
Coating matched to your destination market — zinc / chrome / epoxy / e-coat (480 h+ salt-spray for coastal / humid markets like MENA / SE Asia).
One invoice, one shipment, one lead time. Hardware tooling kicks off when your main equipment order is confirmed; parts ship together. No separate logistics or chasing.
We do not take standalone hardware orders — the value is in the integration with your moulds + foaming machine + assembly line. If you only need hardware (no main equipment), we will refer you to specialist hardware suppliers.
Customization workflow
- 1
You share your drawings (DXF / DWG / PDF) for each hardware item needed. Or pick a reference profile from our catalog as a starting point.
- 2
We quote tooling cost (~USD 1–3K per progressive die, simpler items USD 500) + per-piece price. Tooling is a one-time investment; reorders skip this step.
- 3
Tooling lead time 25–40 days. Sample lot for first-article inspection (FAI) before mass production.
- 4
Mass production runs in parallel with your main equipment build — both finish together.
- 5
Consolidated shipment with the main equipment. One BL, one customs entry.
Download the 17-page hardware reference catalog
Full reference catalog with 70+ standard profiles (photos + dimension drawings) across all 5 categories. Use this as a starting point — pick the closest profile and we customize from there.
